Rud

VLBG load ring will turn 360°, adjustable in pull direction. Load ring foldable, full WLL in any load direction.

  • Material: Forged of high strength steel.
  • Marking: According to standard, CE-marked, WLL
  • Finish: Striking fluorescent pink powder coating.
  • Standard: EN 1677-1
  • Safety factor: 4:1
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
Thread Torque
Nm
T
mm
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
G
mm
H
mm
I
mm
K
mm
L
mm
N
mm
Weight
kg
06.VLBG08PLUS VLBG-PLUS 0.63 M8 30 75 30 54 34 24 40 10 29 11 75 45 40 32 0.3
06.VLBG10PLUS VLBG-PLUS 0.9 M10 60 75 30 54 34 24 39 10 29 15 75 45 44 32 0.32
06.VLBG20PLUS VLBG-PLUS 3.5 M20 400 110 50 82 54 45 55 16.5 43 32 113 64 75 48 1.3
06.VLBG24PLUS VLBG-PLUS 4.5 M24 760 125 50 82 54 45 67 18 43 37 130 78 80 48 1.5
06.VLBG30PLUS VLBG-PLUS 6.7 M30 1,000 147 60 103 65 60 67 22.5 61 49 151 80 110 67 3.3
