- Pivots to 230°, rotates through 360° due to its unique ball earing design.
- Manufactured from forged alloy steel, quenched and tempered.
- Tested in according with EN 1677-4 DNV GL-ST-0378.
- Certified by DNV GL-ST-0378.
- Load rated parts are 100% magnaflux crack detected.
- Individual forged parts and batch code links to Test Certificate sheet.
- Bolts are metric thread.
- Proof tested to 2.5 times the WLL.
- Fatigue rated to 20,000 cycles at 1.5 times the WLL.
- Easy to attach and dismantle due to the forged hexagon shaped body of the DA Swivel point.
- Capable of rotating under load. Do not turn continiously in 90 degree direction of full load.
- Material: Forged Alloy Steel, Quenched and Tempered
- Marking: According to standard
- Standard: EN 1677-1
- Safety factor: 4:1
