Design: Forged.

  • Finish: Galvanized.
4921_e_225mm
4921m_e _225mm
Select a row from the table below, then click the add to quote button
Part Code Code Diameter
mm
A
mm
B
mm
C
mm
L
mm
Weight
kg/100pc
CAD
07.25K202 4908 8 22 9 14 35 8
07.25K2025 4910 9-10 30 11 16 45 10
07.25K203 4912 11-12 35 13 18 55 20
07.25K2035 4914 13-14 45 15 20 65 26
07.25K2035 4916 15-16 50 17 22 75 36
07.25K204 4918 17-18 53 19 25 80 50
07.25K2045 4919 18-19 60 21 29 90 60
07.25K2055 4923 20-23 70 25 34 120 100
07.25K207 4931 29-31 100 33 44 160 180
07.25K209 4936 32-36 115 38 49 185 350
