• Not for lifting

General: Wire rope clips for steel wire rope for general applications.
Design: Forged U-bolt and casted bases.


  • Material: Bases AISI 316, u-bolt AISI 304.
  • Marking: According to standard
  • Standard: DIN 741
  • Note: Follow the fitting instructions in the user manual before use.
kaus_ss
2001m_225mm
Select a row from the table below, then click the add to quote button
Part Code Rope diameter
mm
Weight
kg/100pc
10.162000S 3 1.4
10.162001S 5 1.5
10.162002S 6 2.1
10.162003S 8 4.1
10.162004S 10 6.8
10.162006S 12 13
10.162008S 16 21
