Crosby

General: Fits pin for open wire rope socket, boom pendant clevis and wedge socket.
Design: Cast ductile iron.

  • Finish: Painted.
6003_e_225mm_2
6003m_e_225mm
Select a row from the table below, then click the add to quote button
Part Code Code Rope Ø
mm
A
mm
B
mm
C
mm
L
mm
A tolerance of approx Weight
kg
CAD
10.271037121 6002 13 26,9 54,0 22,4 71,5 ± 5 % 0.28
10.271037149 6003 16 33,3 86 28,7 119 ± 4 % 1
10.271037167 6004 18-20 38,1 86 35,1 119 ± 3 % 1.1
10.271037201 6006 24-26 54 114 46 154 ± 3 % 2.4
10.271037185 6005 22 44,5 114 41,4 154 ± 3 % 2.5
10.271037229 6007 28-30 60,5 137 52,5 184 ± 2 % 4.2
10.271037247 6008 32-35 67 137 58,5 184 ± 2 % 4.5

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
