Crosby

Design:Bolt Type Anchor shackles with thin head bolt – nut with cotter pin. Meets
the performance requirements of Federal Specification R-C-271G, Type IVA, Grade B, Class 3, except for those provisions required of the contractor.

  • Material: Forged Alloy Steel – Quenched and Tempered, with bow and bolt.
  • Marking: According to standard, CE-marked, WLL.
  • Finish: Hot dip galvanized.
  • Standard: EN 13889
  • Safety factor: 8
  • Grade: 8
DNV 2.7-1 approved
Crosby_G2130A_pic
Select a row from the table below, then click the add to quote button
Part Code WLL
ton
Nominal Size (in.) Tolerance +/- A Tolerance +/- C A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
H
mm
L
mm
M
mm
N
mm
Weight
kg
CAD
11.311219472 2 1/2 3.3 1.5 20,6 16 47,8 12,7 33.3 30.2 83.5 58.5 71.1 12.7 0.36
11.311219491 3.25 5/8 6.35 1.5 26,9 19.1 60,5 16,0 42.9 38.1 106 74.5 90.4 17.5 0.62
11.311219516 4.75 3/4 6.35 1.5 31,8 22.4 71,5 19,1 51 46 126 89 105 20.6 1.23
11.311219534 6.5 7/8 6.35 1.5 36,6 25.4 84,0 22,4 58 53 148 102 122 24.6 1.79
11.311219552 8.5 1 6.35 1.5 42,9 28 95,5 25,4 68.5 60.5 167 119 137 26.9 2.28
11.311219578 9.5 1-1/8 6.35 1.5 46,0 31.8 108 28,7 74 68.5 190 131 150 31.8 3.75
11.311219598 12 1-1/4 6.35 1.5 51,5 35.1 119 31,8 82.5 76 210 146 170 35.1 5.31
11.311219614 13.5 1-3/8 6.35 3.3 57,0 38.1 133 35,1 92 84 233 162 183 38.1 7.18
11.311219632 17 1-1/2 6.35 3.3 60,5 41.4 146 38,1 98.5 92 254 175 196 41.1 8.62

Maximum Proof Load is 2 times the Working Load Limit. Minimum Ultimate Strength is 8 times the Working Load Limit.

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD
Download
