General: Low profile lifting beam for handling big bags with four lifting eyes. Fits most bags with the measurements of 75x75 cm to 105x105 cm in the bottom.
Design: The attachment points of the bag´s liftingeyes are leveled with the lifting point of the beam - see drawing. The attachment points are extra thick and round to protect the lifting eyes of the big bag and are also designed to prevent the bag from sliding.
Proof: Batch proof 2 x WLL.

  • Material: Plate of high-strength structural steel.
  • Marking: WLL and CE marking.
  • Finish: Yellow painted.
  • Note: Special design lifting beams with negative lifting height for other dimensions of big bags and loads are also manufactured. We also manufacture lifting beams/spreader for simultaneous handli
Storsäcksok_e_225mm
Storsäcksok_m_lom_225mm
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
A
mm
B
mm
E
mm
H
mm
L
mm
K
mm
Weight
kg
CAD
13.356695015 6695 1.5 80 60 62 170 960 25 26

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD
