Self-balancing — fixed and adjustable forks

General:
For simultaneous lifting of two pallets. Double pallet forks are primarily used in stevedoring, but can also be used in other applications where large quantities of palletized goods are handled.
Design: Thanks to the spring-loaded lifting eye, the pallet fork is self-balancing, which means that the forks always remain horizontal, regardless of whether the pallet fork is empty or not. Please note the minimum load specified in the table. Concealed spring and linkage.
6022-DP - Fixed forks, designed for handling of two special 1200 x 1200 mm pallets.
6030-DP - Adjustable forks designed for handling of two standard pallets from the long side.
6032-DP - Adjustable forks designed for handling of two special 1000 x 1000 mm or 1200 x 1000 mm pallets from the long side.


Proof: Batch proof 1,5 x max last.

  • Material: Hollow-beam and plate of high-strength structural steel.
  • Marking: Minimum load, Maximum load and CE-markning.
  • Finish: Yellow painted.
6022-DP_new_225mm
6022-DPm_new_225mm.
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
Min load kg Tp max A
mm
B (mm) E (mm) H (mm) L (mm) S (mm) Weight
kg
CAD
13.306030DP 6030-DP 3 300 455 840-220 1,900 800 1,500 500 50 230
06.306032DP 6032-DP 3 300 550 840-220 1,900 980 1,500 490 50 240
13.306022DP 6022-DP 3.2 300 650 720 1,990 1,150 1,600 750 60 320
Other dimensions and designs are made on request.
