Gunnebo Industries

Design: Forged according to Swedish standard 1577 type C.



Proof: 2 x WLL.

  • Material: grade 3.
  • Marking: WLL, supplies code and grade.
  • Finish: Galvanized.
  • Safety factor: 4,5:1.
101_e_225mm
2929_lom_225mm
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
Thread d1 D2
mm
A
mm
c*
mm
D
mm
Weight
kg
08.1577C009 107 0.9 M12 28 20 39 11 0.2
*Tolerance: +/- 5%
