Gunnebo Industries

General: The BLP is a very versatile lifting point and can safely be used for most applications. Prevents damages on load surface, can be turned and tilted and is rotating during lift.
Proof load: 2.5 times WLL

  • Safety factor: 4:1
  • Grade: 6
RELP_pic
RELP_dwg
Currently this product cannot be added to an online quote. Please contact us directly for enquires.
Art. No
Code
Dimensions in mm
Weight
B
C
D
L
L1
M
X
Y
Z
kgs
Z102008
BLP-M8 x 1.25
35
55
13
16
112
8
57
61
Ø42
0,6
Z102010
BLP -M10 x 1.5
35
55
13
20
112
10
57
61
Ø42
0,6
Z102012
BLP -M12 x 1.75
35
55
13
24
112
12
57
61
Ø42
0,6
Z102016
BLP-M16 x 2
35
55
13
30
112
16
57
61

Ø42

0,6
Z102020
BLP-M20 x 2.5
34
57
17
30
132
20
75
67
Ø59
1,3
Z102024
BLP-M24 x 3
50
70
17
36
145
24
75
84
Ø59
1,5
Z102030
BLP-M30 x 3.5
54
96
22
45
202
30
106
99
Ø74
3,4
Z102036
BLP-M36 x 4
54
96
22
54
202
36
106
99
Ø74
3,5
Z102042
BLP-M42 x 4.5
70
120
28
63
242
42
122
127
Ø93
6,5
Z102048
BLP-M48 x 5
70
120
28
72
242
48
122
127
Ø93
6,8
Symmetric Load (tonnes)
BLP_1
BLP_2
BLP_3
BLP_4
BLP_5
BLP_6
BLP_7
No. Of legs
1
1
2
2
2
2 symmetric
3&4 symmetric
Angle ß
90°
0-45°
90°
0-45°
45-60°
0-45°
45-60°
Tightening Torque
Spanner Size
BLP -M8 x 1.25 BLP -5/16”-18 UNC
0,6
0,3
1,2
0,4
0,6
0,4
0,3
0,6
0,45
10 Nm
7 Ft.Lbs
36 mm 1 1/2”
0,6
0,3
1,2
0,4
0,6
0,4
0,3
0,6
0,45
BLP -M10 x 1.5 BLP -3/8”-16 UNC
1,2
0,6
2,4
0,8
1,2
0,8
0,6
1,3
0,90
15 Nm
11 Ft.Lbs
36 mm 1 1/2”
BLP
1,0
0,5
2,0
0,7
1,0
0,7
0,5
1,1
0,75
BLP -M12 x 1.75 BLP -1/2”-13 UNC
1,5
0,75
3,0
1,1
1,5
1,1
0,75
1,5
1,1
27 Nm
20 Ft.Lbs
36 mm 1 1/2”
1,5
0,75
3,0
1,1
1,5
1,0
0,75
1,5
1,1
BLP -M16 x 2 BLP -5/8”-11 UNC
3,0
1,5
6,0
2,1
3,0
2,1
1,5
3,1
2,2
60 Nm
44 Ft.Lbs
36 mm 1 1/2”
3,0
1,5
6,0
2,1
3,0
2,1
1,5
3,1
2,2
BLP -M20 x 2.5 BLP -3/4”-10 UNC BLP -7/8”-9 UNC
5,0
2,5
10,0
3,5
5,0
3,5
2,5
5,2
3,7
90 Nm
66 Ft.Lbs
66 Ft.Lbs

50mm 2”
2”

4,5
2,25
9,0
3,1
4,5
3,1
2,25
4,7
3,3
6,0
3,0
12,0
4,2
6,0
4,2
3,0
6,3
4,5
BLP -M24 x 3 BLP -1”-8 UNC
7,0
4,0
14,0
5,6
8,0
5,6
4,0
8,4
6,0
135 Nm
100 Ft.Lbs
50mm 2”
7,0
4,0
14,0
5,6
8,0
5,6
4,0
8,4
6,0
BLP -M30 x 3.5 BLP -1 1/4” -7 UNC
12,0
6,0
24,0
8,4
12,0
8,4
6,0
12,6
9,0
270 Nm
200 Ft.Lbs
65 mm 2 5/8”
12,0
6,0
24,0
8,4
12,0
8,4
6,0
12,6
9,0
BLP -M36 x 4 BLP -1 1/2” -6 UNC
14,0
8,0
28,0
11,2
16,0
11,2
8,0
16,8
12,0
320 Nm
236 Ft.Lbs
65 mm 2 5/8”
14,0
8,0
28,0
11,2
16,0
11,2
8,0
16,8
12,0
BLP -M42 x 4.5 BLP -1 3/4” -5 UNC
16,0
10,0
32,0
14,0
20,0
14,0
10,0
21,0
15,0
600 Nm 440 Ft.Lbs
85 mm
3 1/8”
16,0
10,0
32,0
14,0
20,0
14,0
10,0
21,0
15,0
BLP -M48 x 5 BLP -2”-4.5 UNC
18,0
13,0
36,0
18,2
26,0
18,2
13,0
27,3
19,5
800 Nm 590 Ft.Lbs
85 mm
3 1/8”
18,0
13,0
36,0
18,2
26,0
18,2
13,0
27,3
19,5
