We deliver quality stud link chain, a chain excellent for mooring solutions for the marine fish farming industry

Select a row from the table below, then click the add to quote button
Part Code Diameter
mm
Proof Load K2
kN
ton K3 kN K4 kN Breaking Load K2
kN
p/m p/lock CAD
99.NO4513379800 19 150 23,6 301 421 211 8,1 223
99.NO4513380500 22 200 23,6 401 563 280 11,1 305
99.NO4513381000 24 237 23,6 476 667 332 13,3 366
99.NO4513381200 26 278 23,6 556 779 389 15,7 432
99.NO4513381402 30 368 23,6 735 1,030 514 21 578
99.NO4513381400 32 417 23,6 833 1,170 583 23,9 657
99.NO4513381410 36 523 23,6 1,050 1,460 732 30,2 831
99.NO4513381480 52 1,060 23,6 2,110 2,970 1,480 62 1,705
